Tab. 6: Guide Values for injector pressure (full load)
Model Paramount
Three 60
Paramount
Three 80
Paramount
Three 95
Paramount
Three 115
Nominal heat load Heating kW 12,0-50,0 17,0-70,0 20,0-90,0 25,0-110,0
Nominal heat output 80/60°C kW 11,5-48,5 16,4-67,9 19,4-87,3 24,3-106,8
50/30°C
kW 12,8-51,9 18,3-72,5 21,4-93,1 26,7-113,5
Injector diameter for
Natural Gas LL (G25) mm 7,80 9,30 9,30 11,40
Natural Gas E (G20) mm 7,20 8.50 8.50 10.30
LPG (propane) mm 5,80 7,00 6,50 7,40
Guide values for injector pressure
*
Natural Gas LL (12,4)
**
mbar 6,3-7,3 8,3-8,9 12,5-13,5 12.0-13.0
Natural Gas E (15,0)** mbar 6,3-7,3 8,0-8,6 12,5-13,5 12.0-13.0
Propane mbar 6,3-7,3 7,9-8,5 14,5-15,5 14,5-15,5
the CO
2
-content should be - between 8.3% and 8.8% for natural gas
- for liquid gas be between 10,3% and 10,8%
*
at pressure at end of boiler 0 mbar, 1013 hPa, 15 °C
**
values in brackets = Wobbe Index W
oN
in kWh/m
3
Tab. 7: Guide Values for the gas flow rate for natural gas
Model Paramount
Three 60
Paramount
Three 80
Paramount
Three 95
Paramount
Three 115
Nominal heat load (full load) kW 50,0 70,0 90,0 110,0
Gas Flow Rate in l/min
7 119 167 214 262
7.5 111 156 200 244
8,0 104 146 188 229
Operating heating value
8.5 98 137 176 216
H
uB
in kWh/m
3
9,0 93 130 167 204
9,5 88 123 158 193
10 83 117 150 183
10,5 79 111 143 175
11 76 106 136 167
11,5 72 101 130 159
5.19 Electrical connection
(general)
Risk of electric shock! All electrical work in connection with the installation must
only be carried out by a qualified electrician!
- Mains supply AC 230 V +6% -10%, 50 Hz
The boiler must be installed on an uninterrupted supply with the correct polarity.
For the power supply, use the power cable attached to the boiler or cable types F 3
x 1 mm
2
or 3 x 1.5 mm
2
.
We recommend the installation of a mains isolator upstream of the Paramount.
This should isolate all poles and provide contact separation of at least 3 mm.
Installation
36 Paramount three 30-115 kW 7308272-03 03.14
