Programming
120-393 632.4 04.08 Fh
PARAMOUNT two 30 - 115 kW 43
Relay output 3 RelCl
Default | Message output | Alarm output | Omessage |
External transformer | Heating circuit pump HK2 | Cir-
culation pump | Gate veil function | Pump hydraulic
bypass | Feed pump Q8 | Basic function K2 | TWW-
charging | Threshold analoguous signal RelCl |
Exhaust gas flap | Collector pump | Fan switch-off |
Pump Q1 | DHW mixing pump Q35
5924 I
Default
Relay output 1 SolCl
Default | Message output | Alarm output | Operation
message | External transformer | Heating circuit
pump HK2 | Circulation pump | Gate veil function |
Pump hydraulic bypass | Feed pump Q8 | Basic func-
tion K2 | TWW-charging | Threshold analoguous sig-
nal RelCl | Exhaust gas flap | Collector pump | Fan
switch-off | Pump Q1 | DHW mixing pump Q35
5926 I
Default
Relay output 2 SolCl
Default | Message output | Alarm output | Operation
message | External transformer | Heating circuit
pump HK2 | Circulation pump | Gate veil function |
Pump hydraulic bypass | Feed pump Q8 | Basic func-
tion K2 | TWW-charging | Threshold analoguous sig-
nal RelCl | Exhaust gas flap | Collector pump | Fan
switch-off | Pump Q1 | DHW mixing pump Q35
5927 I
Default
Relay output 3 SolCl
Default | Message output | Alarm output | Operation
message | External transformer | Heating circuit
pump HK2 | Circulation pump | Gate veil function |
Pump hydraulic bypass | Feed pump Q8 | Basic func-
tion K2 | TWW-charging | Threshold analoguous sig-
nal RelCl | Exhaust gas flap | Collector pump | Fan
switch-off | Pump Q1 | DHW mixing pump Q35
5928 I
Default
Function input H1
No | Modem function | Modem function inversely |
Gate veil function | Feed-back Exhaust gas flap| gene-
rator lock | Generaror lock inverse
5950 I
none
Modem function
BA-switch-over HK’s + TWW | BA-switch-over HK’s |
BA-switch-over HK 1| BA-switch-over HK 2
5957 I
BA-switch-over
HK’s + TWW
Configuration Room thermostat 1
None | Room thermostat | timer Room level | timer
heating request | timer TWW level
5970 I
Room thermostat
Configuration Room thermostat 2
None | Room thermostat | timer Room level | timer
heating request | timer TWW level
5971 I
none
Function input RelCl
No | Modem function | Modem function inverse | Gate
veil function | Nominal value specification | Power
specification | Sensor hydraulic bypass | Feed-back
exhaust gas flap | generator lock | generator lock
inverse | Generator lock sensor
5973 I
none
Ext. Flow nominal value maximum
5975 I
100 °C
Ext. Power specification threshold
5976 I
5 %
Function input SolCl
No | collector sensors
5978 I
none
Time constant building
6110 I
10 h
ConfigContr1.0
6240 F
0
ConfigContr1.1
F
0
ConfigContr1.4
F
1
Function
Prog.
-No.
Set-
ting
level
1
Standard value
Modi-
fied
value
