POWER ELECTRONICS
SD300 – PROFINET
SUPPORTED PROFIDRIVE PARAMETERS
39
PNU
R/W
Description
965
R
Indicates the Profile ID. (0h328 – Profile 3 v4.0)
967
R
Displays the control word (STW1) value that is currently
input via the Profinet communication network.
968
R
Displays the status word (ZSW1) value that is currently
input via the Profinet communication network.
972
R/W
The SD300 communication module is reset when the
parameter value is changed to “1” from “0”.
61000
R
Displays the device name of the SD300 Profinet
communication module.
61001
R
Displays the IP address of the SD300 Profinet
communication module.
61002
R
Displays the MAC address of the SD300 Profinet
communication module.
61003
R
Displays the gateway IP address of the SD300 Profinet
communication module.
61004
R
Displays the subnet mask of the SD300 Profinet
communication module.
1000
R/W
SD300 Parameter Access Address (communication
address for reading or writing drive parameters)
1001
R/W
SD300 Parameter Access Data (data value of drive
parameters for reading or writing)
1002
R/W
SD300 Parameter Access Command
1: write
2: read
1003
R/W
SD300 Parameter Access Acknowledge
0: Not completed
1: OK completed
2: Not OK completed
