POWER ELECTRONICS
NB 120
HANDLING AND TRANSPORTATION
29
Removal of the lifting tools
Once the equipment has been anchored, the lifting tool must be removed by following these steps:
1. Open the two side doors of the equipment. First, the door that has a handle. Once opened,
from the inside, it will be possible to unscrew the two M8 screws (one at the top of the
equipment and one at the bottom) to open the other door.
2. Once both doors are open, remove both lifting tools by unscrewing the three M6 screws of
each one.
3. Close the doors again by following the reverse procedure.
NOTICE
If the methods described here cannot be applied, please contact Power Electronics.
It is the customer's responsibility to ensure unhindered access of vehicles to the final site or location,
taking into account their movement and handling at the unloading site.
It is important to keep the equipment in the packaging and place them as close as possible to the final
location for installation.
Ensure that loading/lifting equipment has a greater capacity than the weight of the equipment plus the
auxiliary elements and the loading/lifting task is carried out in a way that ensures the stability of the
equipment.
