PowerMaster SG 2004 Installation Manual

21
operator label. If the operator is connected to an incorrect power supply,
damage will result, which is NOT covered by warranty.
▲ 1. Be sure the power switches at source, and at the operator are OFF.
▲ 2. In the diagram below find the supply power that matches your installation
and connect as shown.
WIRE GAUGE
Line
voltage HP
14 AWG 12 AWG 10 AWG 8 AWG 6 AWG
1/2 150/350 250/400 400/500 500/700 650/1000
3/4 150/250 250/400 400/600 500/850
1 PH
115/
208-
230
1 150/300 250/450 400/700
1/2 450/2000 750/3000 1200/4300
3/4 350/1500 600/2400 900/3700 1100/4500
1 300/1200 450/1900 750/3000 900/4800
3 PH
208-
230
440-
480
1 1/2 200/800 400/1500 500/2000 900/4800
BLK
BLK
BLK
BLK
BLK
BLK
INSIDE UTILITY BOX,
CONNECT AS SHOWN
INCOMING
POWER
OPERATOR
BLK
BLK
BLK
BLK
220 - 1Ø
GND
GND
INSIDE UTILITY BOX,
CONNECT AS SHOWN
INCOMING
POWER
OPERATOR
GND
GND
ALL - 3Ø
UTILITY BOX
BLK
BLK
WHT
WHT
GRN
GRN
INSIDE UTILITY BOX,
CONNECT AS SHOWN
INCOMING
POWER
115V - 1Ø
OPERATOR
UTILITY BOX
LOW VOLTAGE WIRE
GAUGE/DISTANCE CHART
24 AWG: Up to 150'
20 AWG: 150' - 200'
250' - 1,500'
Control wiring should be run as twisted
pairs.
DO NOT run control wires in the
same conduit as power wires. telephone
wires, or loop detector leads.
18 AWG:
22
INSTALLATION OPTIONS
LEFT/RIGHT HAND CONVERSION:
Determine the hand of
the operator required for
this installation by
checking the direction
the gate moves in order
to open, when viewed
from inside the fence.
Slides RIGHT to open is
a right hand installation,
slides Left to open is a
left hand installation.
NOTE: This unit is factory setup
for RIGHT HAND operation. To
convert operator to left hand
operation move dipswitch #2 to
on position.
12
3
4
5
ON
OFF
12
3
4
5
ON
OFF
Place Dipswitch #2
In "ON" Position For Left
Hand Operation And
"OFF" Position For Right
Hand Operation.
Left Hand
Operation
Right Hand
Operation
COM COM COM
24V
AC
24V
AC
ALT
RDO OPN CRO FRE OPN CLO STO
COM
COM COM OPN PHO
CLO
PHO SHW REV
OPN EDG
CLO EDG MST OPN MST CLO COM COM
COM
OPEN
PUS H
FREE
EXT
ALT
RADIO
OPN /
CLO
RADIO
OPEN
CLOSE
PUS H
STO P
PUS H
CLOSE
PHO TO
OPEN
PHO TO
LD18
LD10
LD11
LD12
LD15
LD14
LD16
LD17
LD13
OPEN
CLOSE
STOP
OPEN CLOSE
FORCE
ADJUSTMENT
AUTO
RECLOSE
TIMER
OFF MAX
MID
LIMIT
REV
LOOP
OP N
EDG E
CLO
EDG E
RH OPN
LH CLO
LIMIT
RH CLO
LH OPN
LIMIT
MOTOR
OP EN
MOTOR
CLOSE
SHAD OW
LOOP
LD19
LD2
LD3
LD4
LD5
LD6
LD8
LD9
LD7
12345
POWER
LD1
P3
P4
TB1
TB2
U1
U2
U4
RIGHT HAND
PUBLIC AREA
OR STREET
LEFT HAND
PUBLIC AREA
OR STREET
