14
INSTALLATION INSTRUCTIONS & SET-UP PROCEDURE
BEFORE INSTALLING OPERATOR
IMPORTANT: Operator should always be mounted inside the gate. Determine
whether the installation is Left hand or Right hand by the direction the gate
moves in order to open, when viewed from inside the fence.
DO NOT APPLY POWER UNTIL TOLD TO DO SO! RISK OF
ELECTRICAL SHOCK OR INJURY MAY RESULT!
WARNING
1. Gate must slide freely to fully opened and fully closed position.
2. Gate and/or extension must extend beyond the position of the operator when gate is
in a fully closed position. The operator will be located as shown above, for left and right
hand installation.
PUBLIC AREA
OR STREET
RIGHT HAND
LEFT HAND
PUBLIC AREA
OR STREET
