12
MANUAL DISCONNECT OPERATION
Your operator is equipped with a pad lockable emergency disconnect for manual operation.
Be sure you have a key and understand how to operate this equipment. To disengage
operator, move red disconnect lever to the left and latch it in place. See Figure 1.
WARNING: NEVER OPERATE THE MANUAL RELEASE WHEN THE GATE IS MOVING.
FIGURE 1
NEVER ATTEMPT TO OPERATE THE MANUAL
RELEASE WHEN THE GATE IS IN MOTION!
WARNING
Disconnect
Lever
Padlock
Option Hole
Retaining
Bracket
To Disconnect Drive:
Move lever to the left until it
latches in retaining bracket.
To Re-Engage Drive:
Lift lever to unlatch,
then move lever to
the right.
