TABLE OF CONTENTS
1 Important Safety Warning 3
1.1 Transportation 3
1.2 Preparation 3
1.3 Safety Instruction 4
1.4 Operation 5
1.5 Maintenance, service and faults 5
2 Installation and setup 6
2.1 Package contents 6
2.2 Rear panel view of UPS 6
2.3 Rear panel view of battery pack 7
2.4 Install the UPS 7
2.5 Connecting to Battery Pack 8
2.6 Battery Capacity Extension 10
2.7 Setup the UPS 11
2.8 Battery Replacement 12
3 Operations 13
3.1 Button operation 13
3.2 LCD Panel 13
3.3 Audible Alarm 15
3.4 LCD display wordings index 15
3.5 UPS Setting 17
3.6 Operating Mode Description 22
3.7 Faults Reference Code 23
3.8 Warning indicator 23
4 Troubleshooting 24
5 Service 26
6 Storage and Maintenance 26
7 Specifications 27
1 IMPORTANT SAFETY WARNING
All safety instructions in this document must be read, understood, and followed.
1.1 Transportation and Storage
• Please transport the UPS system only in the original packaging to protect against shock and
damage.
• The UPS must be stored in a facility where the temperature is well regulated. Ambient
temperatures should be between 0–50°C and relative humidity shall be 0–95% non-
condensing. Any storage of greater than 30 days refer to section 8 for more detail.
• The external battery modules are certified under UN38.3 for transport.
1.2 Preparation
• Condensation may form if the UPS system is moved immediately from cold to warm
environment. The UPS system must be dry before being installed. Please allow at least two
hours for the UPS system to acclimatise to the environment prior to energisation.
• If the UPS might be exposed to temperatures over 50C. Please contact PowerShield for
further advise.
