3 OPERATIONS continued
3.5 UPS Setting
Interface Setting
Parameter 2: Output voltage setting
For 220/230/240 VAC models, you may choose the
following output voltage.
220: presents output voltage is 220Vac
230: presents output voltage is 230Vac (Default)
240: presents output voltage is 240Vac
Three parameters need to be configured in order to set up
the UPS. Refer to following diagram.
Parameter 1: It is for the program alternatives. Refer to the
below table.
Parameter 2 and parameter 3 are the setting options or
values of each program.
Parameter 2 Parameter 3 Parameter 1
01: Output voltage setting
Interface Setting
Parameter 2: Enable or disable converter mode.
You may choose the following two options.
CF ENA: converter mode enable
CF DIS: converter mode disable (Default)
02: Converter enable/disable
