Appendix 1 Specifications
Model
10KVA(S/H)
15KVA(S/H)
20KVA(S/H)
Capacity
10KVA
15KVA
20KVA
9KW
13.5KW
18KW
Input
Phase
3 Phase 4 Wires and Ground
Rated Voltage
380/400/415Vac
Voltage Range
208~478Vac
Frequency Range
45-55Hz at 50Hz/54-66Hz at 60Hz (auto sensing)
Power Factor
≥0.99
Current THDi
≤3%(100% nonlinear load)
Bypass Voltage
Range
Max.voltage: 220Vac: +25%(optional +5%,+10%,+15% )
230Vac: +20%(optional +10%,+15% )
240Vac: +15%(optional +10% )
Min. voltage: -45% (optional -20%、-30%)
Frequency protection range: ±10%
Generator Input
Support
Output
Phase
3 Phase 4 Wires and Ground
Rated Voltage
380/400/415Vac
Power Factor
0.9
Voltage Regulation
±1%
Frequency
Utility
Mode
±1%、±2%、±4%、±5%、±10% of the rated
frequency(optional)
Battery
Mode
(50/60±0.2%)Hz
Crest Factor
3:1
THD
≤2% with linear load
≤5% with non linear load
Efficiency
≥93.5% at normal mode
≥94.5% at normal mode
Battery
Voltage
Standard unit: ±120Vdc
(20pcs 12V9AH);
Long run unit :
±96V/±108V/±120Vdc
(16/18/20pcs optional)
Standard unit: ±120Vdc
(2x20pcs 12V9AH);
Long run unit Optional
Voltage:
±96V/±108V/±120Vdc
(16/18/20pcs optional)
Charge Current(A)
(charge current can be
set according
to
battery capacity
installed)
Standard unit: 1.35A
Long run unit: Max.current
10A
Standard unit: 2.7A Long
run unit: Max.current
10A
Transfer Time
Utility to Battery : 0ms; Utility to bypass: 0ms
Protection
Overload
AC
Mode
Load≤110%: last 60min
，
≤125%: last 10min
，
≤150%: last
1min，≥150% change to bypass immediately。
Bat.
Mode
Load≤110%: last 10min，≤125%: last 1min，≤150%: last 5S
，
≥150% shut down UPS immediately。
Bypass
Mode
Breaker 20A
Breaker 32A
Breaker 40A
