2.7 UPS AUXILIARY CONNECTIONS
The communication boards are mounted in the rear UPS section. The standard equipment is composed
of the remote communication board (CS0098) and set-up for the SNMP board.
Access for the connections to these devices is located on the rear part of the UPS (fig.2.7a)
Remote communication board
(CS0098)
SNMP board
Fig. 2.7a
