R&D – USER MANUAL DT0430-E04
3.2.4. MENU 3: UPS COMMANDS
Using this menu it is possible to have operating control to the UPS
MESSAGE MEANING
3.1 SYSTEM START
3.2 SYSTEM STOP
With these commands, pressing ENTER 's user can turn on or turn off the
system
3.3 SWITCH THE LOAD With these commands, pressing ENTER 's user can switch load on inverter or
reserve
3.4 START BATTERY TEST With these commands, pressing ENTER 's user can start battery test
3.5 MANUAL COMMANDS*** Through this menu you have access to all power controls on individual blocks
of the UPS***
***The menu 3.5 is activated and can be used only by authorized personnel
If the operator does not perform any actions for 3 minutes, the “1. UPS STATUS AND ALARMS” menu is automatically
displayed.
3.2.5. MENU 4: PANEL SETUP
MESSAGE MEANING
4.1 DATE SETTING Used to set up the actual date, using the arrows to increase / decrease the
numbers
4.2 TIME SETTING Used to set up the actual time, using the arrows to increase / decrease the
numbers
4.3 PANEL LANGUAGE
SETTING
Used to select the display language available languages
4.4 ALARMS SETUP It allows the user to select the possibility to hide or show a recorded alarm until
the ESC button is pushed
4.5 BATTERY TEST
SETTING
Used to set the periodic battery test, selecting the day of the week, the number
of weeks between the tests and the time of day to start the test
If the operator does not perform any actions for 3 minutes, the “1. UPS STATUS AND ALARMS” menu is automatically
displayed.
3.2.6. MENU 5: EVENTS RECORDER MANAGEMENT
In this menu the user can see last 1023 events / alarms in chronological order.
The event log display can be opened by selecting 5. EVENT LOG in the main menu. The screen will show
the date and time of the last event that occurred.
It is possible to scroll the list using the buttons <BACK or NEXT>
In all positions on the event list, pressing MENU causes the return of the display to the MAIN MENU.
If the operator does not perform any actions for 3 minutes, the “1. UPS STATUS AND ALARMS” menu is automatically
displayed.
