R&D – USER MANUAL DT0430-E04
4.3. UPS START-UP CONFIGURATION
This UPS can be configured in two different start-up mode, the first is “AUTOMATIC” and the second is
“NORMAL”.
The default configuration of the UPS is “AUTOMATIC”
(see chapter 3.2.8)
The two configuration have the following characteristics:
_ AUTOMATIC mode (standard)
This mode initiate a start-up sequential totally automatic of all UPS block.
A scroll bar on the LCD display will show the percentage of advance of the start-up.
After the wizard on the display you can read the message “AUTOSTART PROCESS FINISHED” and a
green LED switch-on on the control panel.
_ NORMAL mode (optional)
This mode initiate a start-up sequential fully automatic from Precharge to the input stadium to ensure a
proper battery charger.
The manual activation by the operator of the inverter stadium complete the start-up procedure, at the end
you will display the message “AUTOSTART PROCESS FINISHED” and a green LED switch-on on the
control panel.
For proper UPS start-up follow the procedure described below.
ATTENTION!
If for any reason should stop the start-up procedure, is necessary perform the “3.2 SYSTEM STOP”
command through the “menu 3. UPS COMMAND”
The start-up sequence will be immediately suspended and the LCD panel displays the message
“AUTOSTART PROCESS INTERRUPTED”
If it is necessary to restart the UPS must use the “3.1 SYSTEM START” command in” menu 3. UPS
COMMAND” or shut down complete the UPS and repeat the start-up as described in the below procedure
