Powertronix spa reserves the right to modify this document without notice
Page 35 of 46
R&D – USER MANUAL DT0430-E04
Follow the below steps to correctly switch on the UPS:
ATTENTION !
The switches in down position means that the circuit is OPEN
The switches in up position means that the circuit is CLOSED
The figure 4.3 presents all the switches in OFF position.
I1
INPUT
MAINS
I2
INPUT
RESERVE
I3
MANUAL
BY-PASS
I4
OUTPUT
UPS
I5
BATTERY
I6
NEUTRAL
ATTENTION !
All the operations described below can be executed by
authorized electrician or qualified personnel only
To Next Page
