Powerware 5105 - Page 13

Installation
7
Powerware
®
5105 User’s Guide S 05146193 A Uncontrolled Copy
Communication Port
6-ft Power Cord
with 5-15 Plug
Load Segment 1
(Three 5-15
Receptacles)
Load Segment 2
(Three 5-15
Receptacles)
Option Slot
Network
Transient Protector
Figure 5. 1000–1500 VA, 120V Rear Panel
Communication Port
Four 10A, IEC-320
Receptacles
Network Transient
Protector
10A, IEC-320 Input
Connector with
6.3A, 250V Fuse
Figure 6. 450–700 VA, 230V Rear Panel
