Installation
4
Powerware
®
5105 User’s Guide S 05146193 A Uncontrolled Copy
WARNING
S This UPS contains its own energy source (batteries). The output receptacles may
carry live voltage even when the UPS is not connected to an AC supply.
S Do not remove or unplug the input cord when the UPS is turned on. This removes
the safety ground from the UPS and the equipment connected to the UPS.
S To reduce the risk of fire or electric shock, install this UPS in a temperature and
humidity controlled, indoor environment, free of conductive contaminants. Ambient
temperature must not exceed 40
°C (104°F). Do not operate near water or
excessive humidity (95% max).
S To comply with international standards, the sum of earth leakage current from the
load connected to the UPS must not exceed 1.5 mA.
Installing the UPS
The following steps explain how to install the UPS. Figure 2 shows a
typical installation only. See “UPS Rear Panels” on page 6 for the rear
panel of each model.
NOTE Do not make unauthorized changes to the UPS; otherwise, damage may occur
to your equipment and void your warranty.
1. If you are installing power management software, connect your
computer to the UPS communication port using the supplied
communication cable.
Some power management software has a Load Segment feature
that allows you to control UPS output receptacles. If you plan
to use this feature, read the appropriate sections of your power
management software manual before you install the UPS.
2. On 230V models, plug the UPS power cord into the input
connector on the UPS rear panel.
