PPI claveX Series User Manual

11
SLAVE ID
(Available for Utility Option ‘Serial Comm.’ only)
This parameter assigns a unique identification number that the
Master Device can use to address the instrument for data
transactions.
PAGE-11 : SUPERVISORY PARAMETERS
Parameter Description
Settings
(Default Value)
Table 6.1
PASS CODE FOR CYCLE ABORT
Set the pass code that the operator must enter if he needs to abort
a running autoclave cycle by setting the Abort command to ‘Yes’
on the operator page.
OPERATOR PARAMETER LOCKING
Setting this parameter to ‘Yes’ enables the supervisor to disallow
the operator to edit the Control Setpoint, Air Outlet Setpoint and
the Soak Time duration on the Operator Page.
DIGITAL FILTER FOR TEMPERATURE VALUE
This value determines the averaging rate of change of Measured
Temperature Value and thus helps removing undesired rapid
changes in the measured . The higher the filter Temperature Value
value the better the averaging but the slower the response to
actual changes.
OFFSET FOR TEMPERATURE VALUE
This parameter adds positive or negative offset to the Measured
Temperature Value for removal of thermal gradient or known
sensor error.
(Default : )22
1 to 250
0.5 to 25.0 Seconds
in steps of 0.5 Seconds
(Default : )1.0
-1999 to 9999 or
-199.9 to 999.9
(Default : )0.0
(Default : )No
Yes
No
1 to 127
(Default : )1
Section 6
User Manual
Clave
UTILITY OPTION
None
No optional utility module is fitted / functional.
Serial Communication
The optional utility module is RS485/RS232 serial communication
port.
Cycle Start
The optional utility module is Digital Input (potential-free contact
closure) for Cycle Start Command. An open to close contact will
initiate a new Autoclave Cycle.
Water Level
The optional utility module is Digital Input (potential-free contact
closure) for Water Level checking.
(Default : None)
None
Serial Comm.
StartCycle
Water Level
