CYCLE ABORT PASS CODE
After setting the Cycle Abort Command to ‘Yes’, set this pass code
to an appropriate value for actual cycle abortion.
CYCLE ABORT COMMAND
Set to ‘Yes’ (to be followed by proper pass code entry) to abort a
running autoclave cycle.
FAIL-SAFE DEVIATION SETPOINT
The positive deviation value above the control setpoint for
automatic abortion of the cycle for safety. Upon abortion, the
heater is switched off and the air outlet valve is opened to release
the pressure.
The positive deviation value above the control setpoint for
Process High Alarm.
HIGH ALARM DEVIATION SETPOINT
SOAK TIME
The time duration in ‘Minutes’ for which the autoclave temperature
is maintained at the set control setpoint value.
AIR OUTLET SETPOINT
The setpoint value at and above which the Air Outlet valve is kept
closed to build saturated steam pressure.
The Setpoint value at which the autoclave temperature value is
maintained for the set soak time duration.
CONTROL SETPOINT
(Default : )100.0
Setpoint Low Limit to
Setpoint High Limit
3. Use UP/DOWN keys to adjust the value and then press ENTER key to store the set value and scroll to the next parameter.
The controller automatically reverts to MAIN Display Mode upon scrolling through the last operator parameter. Alternatively,
use PAGE key to return to MAIN Display Mode.
The Operator Parameters are described in Table 2.2 below.
Setpoint Low Limit to
Setpoint High Limit
(Default : )121.0
Parameter Description
Settings
(Default Value)
Table 2.2
1 to 999 Minutes
(Default : 20)
1 to 10 or
0.1 to 10.0
(Default : 5.0)
3 to 20 or
0.3 to 20.0
(Default : 10.0)
0 to 250
(Default : 0)
Yes
No
