Electrical specifications - INPUT type 5514A1:
TC input:
Max. offset ................................................. 50% of selected max. value
Basic accuracy:
Type E, J, K, L, N, T, U ........................... < ±1°C
Type B, R, S, W3,W5 ............................. < ±2°C
Cold junction compensation ...................... < ±1°C
Temperature coefficient
Type E, J, K, L, N, T, U:
span < 500°C ...................................... < ±0.05°C / °C
amb.
span > 500°C ...................................... < ±0.01% of span / °C
amb.
Type B, R, S, W3, W5 ............................ < ±0.2°C / °C
amb.
Sensor error detection ............................... Yes
Sensor error current:
when detecting ...................................... Nom. 33 µA
else ......................................................... 0 µA
mV input:
Measurement range ................................... 0...100 mV
Min. measurement range ........................... 5 mV
Max. offset ................................................. 50% of selected max. value
Input resistance .......................................... Nom. 10 M
33
ELECTRICAL SPECIFICATIONS:
Specifications range:
-20°C to +60°C
Common specifications:
Supply voltage:
5514A-A ..................................................... 103.5...126.5 VAC, 50...60 Hz
5514A-B ..................................................... 207...253 VAC, 50...60 Hz
5514A-D ..................................................... 19.2...28.8 VDC /
21.6...26.4 VAC, 50...60 Hz
Internal consumption ................................. < 3.5 W
Max. consumption ..................................... 4 W
Isolation voltage test / operation ............... 3.75 kVAC / 250 VAC
Communication .......................................... Loop Link
Response time (programmable) ................. 1...60 s
Signal dynamics, input ............................... 20 bit
Calibration temperature ............................. 20...28°C
Temperature coefficient .............................. < 0.01% of span / °C
Linearity error ............................................. < ±0.1% of span
Effect of supply voltage change ................ 0.002% of span / % V
Auxiliary voltage 5514 A2:
2-wire supply .............................................. 20 VDC / 20 mA
EMC immunity influence ............................ < ±0.5% of span
Max. wire size ............................................. 1 x 2.5 mm
2
stranded wire
Screw terminal torque ................................ 0.5 Nm
Relative air humidity ................................... < 95% RH (non-cond.)
Dimensions (HxWxD) .................................. 48 x 96 x 120 mm
Panel cut-out .............................................. 44.5 x 91.5 mm
Tightness (mounted in a panel) .................. IP65
Weight ........................................................ 330 g
32
Min. Max. Min. span
Type temp. temp. (5 mV) Standard
B +400°C +1820°C 200°C IEC584
E -100°C +1000°C 50°C IEC584
J -100°C +1200°C 50°C IEC584
K -180°C +1372°C 50°C IEC584
L -100°C +900°C 50°C DIN43710
N -180°C +1300°C 100°C IEC584
R -50°C +1760°C 200°C IEC584
S -50°C +1760°C 200°C IEC584
T -200°C +400°C 50°C IEC584
U -200°C +600°C 75°C DIN43710
W3 0°C +2300°C 200°C ASTM E988-90
W5 0°C +2300°C 200°C ASTM E988-90
