PR Lighting XR 200 BEAM User Manual

2/22
INDEX
SAFE USAGE OF THE PROJECTOR
3
INSTALLING THE PROJECTOR
4
FITTING LAMP
4
POWER SUPPLY – MAINS
5
CONTROL CONNECTIONS
5
DMX TERMINATOR
6
SETUP OPTIONS-PROJECTOR CONFIGURATION
6
TO SET THE DMX START ADDRESS
6
STAND-ALONE MODE
7
MASTER/SLAVE MODE
7
OPERATION MENU
7
DMX PROTOCOL
10
INDICATION OF LED DIGITAL TUBE
14
MAINTENANCE
15
LUBRICATION
15
KEEPING THE PROJECTOR CLEAN
15
TROUBLESHOOTING
15
TECHNICAL DATA
16
ELECTRICAL DIAGRAM
18
COMPONENT ORDER CODES
19
Please note that as part of our ongoing commitment to continuous product development, specifications are subject to change without notice. Whilst
every care is taken in the preparation of this manual we reserve the right to change specifications in the course of product improvement. The
publishers cannot be held responsible for the accuracy of the information herein, or any consequence arising from them.
Every unit is tested completely and packed properly by the manufacturer. Please make sure the packing and / or the unit are in good condition
before installation and use. Should there be any damage caused by transportation, consult your dealer and do not use the unit. Any damage caused
by improper use will not be assumed by the manufacturer and / or dealer.
ACCESSORIES
These items are packed together with the projector:
Name Quantity Unit Remark
G clamps 2 Pcs
XLR cable 1 Pc with plug
Safety cord 2 Pcs
This manual 1 Pc
Ω clamps 2 Pcs Optional
