9113 TEMPERATURE / mA CONVERTER Safety Manual
Action Display shows
15 Verify CJC type and press OK
(ONLY IF SENSOR = TC and CH1.TYP = TEMP)
O.RANGE
16 Verify fixed output range and press OK OUT.ERR
17 Verify fixed output value on detected sensor error
and press OK
(ONLY IF CH1.TYP = TEMP, or IF I.RANGE = 4-20
mA)
OUT.LO
18 Verify temperature for 0% output and press OK
(ONLY IF CH1.TYP = TEMP)
OUT.HI
19 Verify temperature for 100% output and press OK
(ONLY IF CH1.TYP = TEMP)
RESP
20 Verify analogue output response time and press OK CH2.TYP
21 Verify input type for Channel 2 and press OK I.RANGE
22 Verify fixed input range and press OK
(ONLY IF CH2.TYP = CURR)
CONNEC
23 Verify sensor connection type and press OK
(ONLY IF SENSOR = Ni or Pt and CH2.TYP =
TEMP)
UNIT
24 Verify temperature unit and press OK
(ONLY IF CH2.TYP = TEMP)
SENSOR
25 Verify temperature sensor type and press OK
( ONLY IF CH2.TYP = TEMP)
Pt.TYPE
26 Verify Pt sensor type and press OK
(ONLY IF SENSOR = Pt and CH2.TYP = TEMP)
Ni.TYPE
