16 Version No. V6R0
Safety Manual 9113 TEMPERATURE / mA CONVERTER
Action Display shows
27 Verify Ni sensor type and press OK
(ONLY IF SENSOR = Ni and CH2.TYP = TEMP)
TC.TYPE
28 Verify Thermocouple type and press OK
(ONLY IF SENSOR = TC and CH2.TYP = TEMP)
CJC
29 Verify CJC type and press OK
(ONLY IF SENSOR = TC and CH2.TYP = TEMP)
O.RANGE
30 Verify fixed output range for current output OUT.ERR
31 Verify fixed output value on detected sensor error
and press OK
(ONLY IF CH2.TYP = TEMP, or IF I.RANGE = 4-20
mA or 20-4 mA)
OUT.LO
32 Verify temperature for 0% output and press OK
(ONLY IF CH2.TYP = TEMP)
OUT.HI
33 Verify temperature for 100% output and press OK
(ONLY IF CH2.TYP = TEMP)
RESP
34 Verify analogue output response time and press OK CH1.CAL
35 Verify the use of applied process calibration values
for Channel 1 and press OK
CH2.CAL
36 Verify the use of applied process calibration values
for Channel 2 and press OK
PASSW.
37 Verify password and press OK SIL.OK
38 Verify SIL mode within 1 second
