PRECITEC CHRocodile C - Page 37

38
DWD
<0..n1><0..n2>
[<0..n1><0..n2>]
…
<0..n1><0..n2>
[<0..n1><0..n2>]
...
Detection WinDow
Up to 16 windows (window1left, window1right,
window2left, window2right...), in micrometers
See also: LMA
ENC
<0..4> [<0..3>]
< -2147483648 ..
4294967295, ?>
-
ENCoder Position:
$ENC <axis#> <function> <arg>
-index of axis -optional: Function
-position (treated modulo 2^32)
Defined functions:
• 0: Set / Read Pos.
• 1: set count source <value>
(0..9: A0, B0, A1, B1, . . . ; 10:
SyncIn; 11..14: n.a., 15: Quardr.)
• 2: set preload value <value>
• 3: set preload event <value>
- Query currently supported for
position only.
For detailed description see
below
ETR
<func. Index>
<arguments>
-
Encoder TRigger
For detailed description see below
FDK
[<1..300>]
[<0..32767>]
(<x>)” x being the (virtual) exposure
rate in Hz at which the CCD would
saturate
Fast Dark
The dark reference is taken with current exp. settings
and is not stored to nonvolatile memory.
When changing the exposure settings, the dark settings
acquired by the last DRK command are restored.
See also: DRK, CRDK
IDE
IDEntification
String with key-value pairs that enable identification of
the device
IPCN
<0,1>,
[eight numbers
<0..255>]
<DHCP, IP address, subnet MASK>
IP-Address change
Configure TCP address and subnet mask. 1st arg: DHCP
on/off, args 2.5: fixed IP addr. args 6..9: subnet mask
(only if DHCP off, i.e. 1st arg = 0)
LAI
<0…100, ?>
<value in %>
LAmp Intensity
Set on-time of LED between 1-100% of the exposure time.
This command also disables the autoadapt mode!
LTC
LaTenCy
Experimental parameter, is not saved to nonvolatile.
Determines the time after which a packet is closed and
sent.
Default 1ms.
LMA
<0,1, ?>
<0,1>
LiMits Active
Detection Limits active, 0(default) or 1. See also: DWD
See also: DWD
MOD
<0,1,127, ?>
either:
0 (confocal, 1 surface) or:
1 (confocal, 2 surfaces) or:
127 (more than 2 peaks)
measurement MODe
For compatibility: 0: one surface (default), 1: thickness,
127: different mode (detect more than 2 peaks)
