Installing the Console 47
Table 2. P80 internal cable connections
Cable Connector Type Circuit
Connector
Location
Ethernet (LAN) Eight-contact modular,
on round black cable
TV in F-type coaxial
Power Split power cable
Data from base unit Eight-contact modular,
on flat gray cable
Heart rate sensors Four-contact strip, keyed
Safety key (treadmills
only)
Six-contact strip, keyed
CSAFE Eight-contact modular,
on flat gray cable
Automatic stop
sensor (treadmills
only)
Vertical four-contact
strip, keyed
To simplify installation and maintenance, route and connect
cables 1 through 5 according to the following instructions.
Note: In the illustrations in this section, some cables are
omitted for the sake of clarity.
