Precor C966 Serivce Manual

C966 Treadmill
Page 4
Procedure 2.1 — Accessing the Diagnostic Software
The treadmill's diagnostic software consists of the following modes:
• Display Test
• Keyboard Test
• Heart Rate Test
• Lift Test
• Belt Speed Test
• Belt Power Test
• Circuit Breaker Test
Procedure
1. Plug the power cord into the wall outlet, then turn on the treadmill with the circuit breaker.
2. The keys on the display are hypothetically numbered 1 to 7 from left to right. See Diagram
2.1. The STOP is key number 4 and is located directly below the QUICK START key.
3. With the PRECOR banner scrolling, press keys RESET,5,1,7,6,5,7,6,1, sequentially. The
display test will be initiated.
4. Watch the electronic display as the display test progresses. This test illuminates all of the
LED’s on the display. If all of the LED’s do not illuminate, replace the upper PCA per
Procedure 5.2 of the Commercial Treadmill Service Manual.
5. Press the STOP or ENTER key to proceed to the keyboard test.
Diagram 2.1 — C966 Treadmill Display
Key #1
Key #7

Precor C966 Specifications

Power

motor	4.0 hp continuous duty
power at 120 V	120 v @ 50/60Hz 20 Amps
power at 240 V	240v @ 50/60Hz 20 Amps

Performance

speed	0.5 to 16 mph (1 to 26 kph)
incline	- 3% to 15% grade
frame	Powder-coated steel

Weight and Dimensions

length	86 inches (218 cm)
width with handrails	37 inches (93 cm)
width without handrails	34 inches (86 cm)
height	59 inches (150 cm)
weight	375 lbs (170 kg)
shipping weight	470 lbs (213 kg)
running surface	60 inches x 20 inches (153 cm x 51 cm)
