Precor C966 Serivce Manual

C966 Treadmill
Page 41
Procedure 6.7 — Replacing the Line Cord
1. Set the treadmill circuit breaker in the “off” position and unplug the treadmill’s line cord from
the AC outlet.
2. These units are equipped with a detachable line cord. Loosen the line cord clamping screw.
See Diagram 6.7.
Diagram 6.7 - Detachable Line Cord
3. Remove the line cord from the line cord socket.
4. Insert the replacement line cord in the line cord socket, be sure that the line cord is fully
engaged with the line cord socket. Tighten the line cord socket clamping screw. It is
extremely important that the line cord is fully engaged in the line cord socket. A poor
connection between the line cord and line cord socket can generate enough heat to damage
the line cord and/or line cord socket.
5. Check treadmill operation per Section 3.
Clamping
Screw

Precor C966 Specifications

Power

motor	4.0 hp continuous duty
power at 120 V	120 v @ 50/60Hz 20 Amps
power at 240 V	240v @ 50/60Hz 20 Amps

Performance

speed	0.5 to 16 mph (1 to 26 kph)
incline	- 3% to 15% grade
frame	Powder-coated steel

Weight and Dimensions

length	86 inches (218 cm)
width with handrails	37 inches (93 cm)
width without handrails	34 inches (86 cm)
height	59 inches (150 cm)
weight	375 lbs (170 kg)
shipping weight	470 lbs (213 kg)
running surface	60 inches x 20 inches (153 cm x 51 cm)
