Precor C966 Serivce Manual

C966 Treadmill
Page 32
Procedure 6.2 — Replacing the Lift Platform
1. Set the treadmill circuit breaker in the “off” position. Remove the AC line cord from the AC
outlet.
2. Remove the treadmill hood. Carefully, lay the treadmill on it’s right side.
3. Remove the hitch pin and clevis pin that fastens the lift motor tube to the lift platform. While
the lift tube is not fastened to the lift platform, care must be taken to not allow the lift tube to
rotate. If the lift tube rotates, the lift motor must be re-calibrated per Procedure 4.1.
4. Remove the lift platform retaining bolt from both the left and right hand side of the lift
platform. See diagram 6.1.
Diagram 6.1 - Lift Platform Mounting)
5. Slide a 5/32 inch allen wrench or similar slender tool into the alignment hole as shown in
Diagram 6.2. Pull the right hand (lower) lift pin out of the treadmill frame.
Retaining
B
Retaining
Bolt
Alignment
Hole
Lift
Platform
Lift Pin

Precor C966 Specifications

Power

motor	4.0 hp continuous duty
power at 120 V	120 v @ 50/60Hz 20 Amps
power at 240 V	240v @ 50/60Hz 20 Amps

Performance

speed	0.5 to 16 mph (1 to 26 kph)
incline	- 3% to 15% grade
frame	Powder-coated steel

Weight and Dimensions

length	86 inches (218 cm)
width with handrails	37 inches (93 cm)
width without handrails	34 inches (86 cm)
height	59 inches (150 cm)
weight	375 lbs (170 kg)
shipping weight	470 lbs (213 kg)
running surface	60 inches x 20 inches (153 cm x 51 cm)
