EFX576i Elliptical Fitness Crosstrainer Assembly Guide 2
Hardware Kit (not to scale)
Fasteners Quantity
(A) Buttonhead screw (1-inch)
14
(B) Washer (⁵⁄₁₆-inch)
20
(C) Socket head cap screw (1¼-inch)
6
(D) Split washer (⁵⁄₁₆-inch)
14
(E) Hex head screw (1¼-inch)
2
(F) Washer (³⁄₈-inch)
4
(G) Self-tapping screw (1½-inch)
4
(H) Phillips-head screw (¾-inch)
3
2 — Bushings (J)
2 — Link arm caps (K)
2 — Pivot arm caps (L)
