Precor C966i Service Manual

C956i, C966i (Gen 06) Treadmill
Page 1-34 Page 34
Procedure 6.3 - Replacing the Power Control Module
1. Set the treadmill’s on/off switch in the “off” position and remove the AC line cord from the AC
outlet.
2. Remove the treadmill’s hood.
3. Disconnect the COMM, INCLINE, INPUT, DB and OUTPUT connectors from the power
control module. See Diagram 5.3 and 5.4.
4. Remove the four screws that mount the power control module. See Diagram 6.3.
Diagram 6.3 - Power Control Module Mounting
5. Set the replacement power control module in its mounting position.
6. Fasten the power control module with the four screws removed in step 4.
7. Reconnect the COMM, INCLINE, INPUT, DB and OUTPUT connectors removed in step 3.
The mating connectors on the power control module are polarized, therefore they can not be
reconnected incorrectly.
8. Replace the treadmill’s hood.
9. Thoroughly check the treadmill per Section 3.
Mounting
Screw
Power
Control
Module

Precor C966i Specifications

Power and Motor

motor power	4.0 hp continuous duty
power requirements 120v	120 v @ 50/60Hz 20 Amps
power requirements 240v	240v @ 50/60Hz 20 Amps

Performance

speed range	0.5 to 16 mph (1 to 26 kph)
incline range	-3% to 15% grade

Weight and Dimensions

length	86 inches (218 cm)
width with handrails	37 inches (93 cm)
width without handrails	34 inches (86 cm)
height	59 inches (150 cm)
weight	375 lbs (170 kg)
shipping weight	470 lbs (213 kg)
running surface	60 inches x 20 inches (153 cm x 51 cm)
