Owner’s Manual: EFX Features 9
EFX Features
The EFX is equipped with features designed to help you
meet your fitness goals. These features include:
• Stationary handgrips with heart rate feature
• Moving handlebars
•Preset programs
• Comprehensive resistance settings
• Automatic crossramp
The Locking Pin
CAUTION: Always use the locking pin to secure the
foot pedals when the EFX is not in use.
The locking pin secures the foot pedals to keep them from
traveling up or down the ramp. Before beginning your
exercise session, pull firmly on the pin to slide it out of the
roller arm. Refer to Diagram 2. A lanyard attaches the
locking pin under the ramp.
Store the locking pin underneath the ramp once it is
removed from the roller arm. Refer to Diagram 3. After
exercising, use the locking pin to secure the foot pedals.
Diagram 2: Remove locking pin before exercising
Diagram 3: Store the locking pin under the ramp
