EFX5.25 Elliptical Fitness CrossTrainer Assembly Guide 3
Assembly Steps
Important: Read the Installation Requirements before assembling
the EFX.
Ask your assistant to hold the right stabilizer, which has the cable
protruding from both ends, next to the base frame. Connect the
base cable. An audible click is heard when the cable is properly
attached. Place excess cable into the base frame.
Secure the stabilizer to the base frame using four hex head screws
(A) and four washers (B). Partially tighten.
Note: For easier access to the base mounts, lift the front of the
EFX off the floor and place a wedge of packaging beneath its base.
