COMMERCIAL PRODUCTS DIVISION
Thank you for purchasing the self-powered Precor EFX
®
524.
Important: Before using the EFX, we urge you to familiarize yourself and your
staff with the entire Owner’s Manual. Understanding this manual will help you and
your customers use the EFX safely and successfully.
Your EFX is carefully inspected before shipment so it should arrive in good operating
condition. Precor ships the unit in the following pieces:
❑ Base frame assembly ❑ Base frame stabilizers (left and right)
❑ Upright support ❑ Display console assembly
❑ Handrails (left and right) ❑ Bracket and side covers
❑ Hardware kit and owner’s manual
CAUTION: This unit weighs over 183 pounds (82 kilograms). To prevent
injury to yourself or damage to the equipment, obtain appropriate assistance
before removing the unit from the pallet.
If any items are missing, contact your Precor Commercial Products Service Repre-
sentative at 1-888-665-4404.
STANDARD EQUIPMENT
The EFX
®
524 incorporates the Precor Smart Rate
®
and Heart Rate features into its
display console. Devices, such as FitLinxx
®
, that are CSAFE compatible, can also
be attached.
Note: An optional POLAR
®
chest strap can be purchased and worn during a workout.
The chest strap transmits the user’s heart rate to the display console’s receiver.
OTHER EQUIPMENT
Optional equipment available through your dealer includes:
• Battery recharger
• POLAR
®
chest strap.
If you are interested in obtaining Precor option kits for your unit, check with your
dealer. For customer service, see
Obtaining Service
on page 5.
ACQUIRING THE APPROPRIATE TOOLS
Obtain the following tools
before
assembling the EFX.
❑ Wire cutter ❑ Phillips head screwdriver
❑ Rubber mallet ❑ Hex torque wrench
❑ Two 9/16” combination wrenches (open-end and box)
❑ SAE Standard socket set with socket extension for 1/2-inch and
9/16-inch bolts
Unpacking the EFX
®
