COMMERCIAL PRODUCTS DIVISION
UNPACKING THE EFX544
Your EFX544 is carefully inspected before shipment so it should arrive in good
operating condition. Precor ships the unit in the following pieces:
• base frame assembly
• upper column support
• front cover
• electronic console display
• reading rack
• handrails (left and right)
• hardware kit, power cable, Owner’s Manual, and limited warranty card
(The hardware kit is shown in Diagram 1.)
To remove the EFX544 from the wood pallet, be sure to ask for assistance from
more than one adult.
CAUTION: This unit weighs over 300 pounds (135 kilograms). To avoid
back strain and ensure the safety of the unit and yourself, we suggest that
you get assistance before removing the unit from the pallet.
INSTALLATION REQUIREMENTS
Follow the installation requirements below when installing the EFX544.
If you do
not install the EFX544 according to the following guidelines, you could void the
Precor limited warranty.
• Set up the EFX544 on a solid, flat surface. A flat surface is required for
your safety and proper use of the EFX544.
• Fill out and mail the limited warranty card. The serial number is located
on a label inside the rear cover. Stand to the left of the unit as you face the
electronic console and move the left foot pedal into its lowest position. Bend
down and look inside the rear cover. On the center tube, you can see the
serial number label.
• Use the appropriate voltage, dedicated circuit, and grounding as
specified on the EFX544. The EFX544 is available in a 120-volt and a 240-
volt model. Refer to the EFX544’s identification label to determine the
voltage, power cord, and plug that your EFX544 requires. Make sure that the
EFX544 is connected to a power outlet that has the same configuration as
the plug.
CAUTION: Use the appropriate power cord and plug for your unit. Do not
use a non-grounded outlet. Electrical damage can occur if the EFX544 is
connected to an improper power source.
Setting Up the EFX544
