Auto Stop Troubleshooting

Apple To: TRM6000-18, TRM700-16, TRM800-14

/18and later treadmill models

This troubleshooting procedure only applies to treadmill models that utilize software and

drive motor current input to manage the auto stop function. For early production models like

the TRM10

treadmill that utilize mechanical magnetic sensor input to manage the auto

stop function, refer to the Error Code Troubleshooting Guide for troubleshooting inform-

ation.

Auto stop is a safety feature that shuts off a treadmill that has been abandoned while the

belt is running. Exclusive of the first sixty seconds after a workout has begun or resumed,

any 30 second window with no user detected will prompt a 10 second countdown and then a

full stop. The detection is accomplished through software and is rated to detect persons

weighing 50 lbs (22.7kg) or greater walking with a normal cadence.

The feature is selectable ON or OFF in the facility settings menus. It is default from the fact-

ory set to ON, and it is recommended to be set ON.

Related Error Codes

ERROR CODE DESCRIPTION

none

Troubleshooting Procedure

Access the Hardware Validation (51765761) and select the Auto Stop test.

P10, P30, P30i and P31 consoles:

When the feature is enabled, the " USER DETECTED" message is shown if motion is detec-

ted from the running deck or NO USER DETECTED if no motion is detected. It may take 5

or 6 steps for the USER DETECTED message to be displayed. This cycle will start over if

the speed is changed.

P62, P80, and P82 consoles:

When START is pressed, after a few steps, the status line will show USER DETECTED and

the STEP COUNT will indicate the number of steps. If steps are not detected, the NO USER

DETECTED message will be shown in the status field.

If the Auto Stop Feature did not pass the test replace the motor controller module.
