Precor move beyond S3.15 Assembly Instructions

S3.15/S3.19 Leg Press Option Assembly Instructions
page 6
1 2 3 4 5 6
3
Assembly
Instructions
Assembly Instructions
Assembly of the Leg Press Option takes professional
installers about ¹⁄₂ hour to complete. If this is the first
time you have assembled this type of equipment, plan
on significantly more time.
Professional installers are highly recommended!
However, if you acquire the appropriate tools, obtain
assistance, and follow the assembly steps sequentially,
the process will take time, but is fairly easy.
CAUTION: Obtain assistance! Do not attempt to
assemble the Leg Press Option by yourself. Review
the
Installation Requirements before proceeding
with the following steps.
With so many assembled parts, proper alignment and
adjustment is critical. While tightening the fasteners, be
sure to leave room for adjustments. Do not fully tighten
fasteners until instructed to do so.
Important: Be careful to assemble components in the
sequence presented in this manual.
Seat Bracket
Support
Crossbrace
Footrest
Leg Press Arm

Precor move beyond S3.15 Specifications

Weight and Dimensions

length	72 inches (182 cm)
height	83 inches (211 cm)
width	51 inches (130 cm)
shipping weight	221 lb (100 kg)
