Precor move beyond S3.23 User Manual

S3.23 Assembly and Maintenance Guide
page 16
1 2 3 4 5 6
5. Move the Pulley Assemblies
A. To raise the Pulley Assembly, simply push the
Handle up along the track. The Pulley Assembly
automatically locks into position.
To lower the Pulley Assembly, lift the Handle up so
it disengages from the track and then lower the
Pulley Assembly. Let go of the Handle to lock the
Pulley Assembly into position.
Step 5. Move the Pulley Assemblies
A
Pulley
Assembly
Handle
To disengage the Pulley Assembly, lift the
Handle and slide the assembly along its track.

Precor move beyond S3.23 Specifications

Weight and Dimensions

length	38 inches (97 cm)
height	83 inches (211 cm)
width	52.5 inches (133 cm)
shipping weight	289 lb (131 kg)
