Precision Series / Energy Series EFX Owner's Manual:: EFX 447 / 245 10
Using the Locking Pin
Your EFX is equipped with a pin and lanyard to lock its
pedals (and arms, if it has moving arms) in place. To
lock the EFX, insert the pin securely into one of the
holes just behind the rollers.
Important: The locking, spring-loaded ball near the end of
the pin must pass through both sides of the arm. You
should be able to feel it when it clicks into place.
The following figure shows how the pin looks when it is
properly seated.
Figure 4: Locking pin in use
When you want to use the EFX, remove the pin from
the hole and store it in the hole under the bottom of
the ramp. The following figure shows how the pin
should look while the EFX is in use.
Figure 5: Locking pin in storage during a workout
