Precor SPINNER CLIMB User Manual

Handlebar Assembly Replacement
About
This procedure provides instruction to remove and install the Handlebar Assembly.
Procedure
Review entire procedure before starting.
Removal Instructions
1. (Spinner® Chrono
1
™ Power models only)
Remove the four 4 mm (4x) hex key bolts and remove the console backplate cover.
Disconnect the data COMM cable from the console and set the console aside, see
the "SPINNER
®
CHRONO™ CONSOLE" Operator's Guide.
2. Remove the rear handlebar post slider end cap by removing the two 2.5 mm hex key
bolts. Retain for installation.
1
Spinner® Chrono™ Power bike.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 100
5 Replacement Procedures
Handlebar Assembly Replacement
