Precor SPINNER CLIMB User Manual

Handlebar Post Removal
About
This procedure provides instruction to remove and install the handlebar Post.
For Spinner® Chrono
1
™ Power models, the data COMM cable must be removed from the
inside the handle bar post weldment to remove the handlebar post.
Select procedure:
l
Spinner® Chrono™ Power
l
Spinner® Climb™
Procedure - (Spinner® Chrono™ Power models only)
Review entire procedure before starting.
Removal
1. Remove the four 4 mm (4x) hex key bolts and remove the console backplate cover.
Disconnect the data COMM cable from the console and set the console aside, see
the "SPINNER
®
CHRONO™ CONSOLE" Operator's Guide.
1
Spinner® Chrono™ Power bike.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 106
5 Replacement Procedures
Handlebar Post Removal

Precor SPINNER CLIMB Specifications

General

Brand	Precor
Model	SPINNER CLIMB
Category	Exercise Bike
Language	English
