Drive Belt, Generator Belt, and Flywheel Replacement
Applies To: (Spinner® Chrono
1
™ Power models only)
About
This procedure provides instruction to remove and install the Drive Belt, Generator Belt, and
Flywheel.
Drive belt and generator belt replacement requires removal of the flywheel so this one pro-
cedure provides removal and installation procedures for the flywheel, drive belt and gen-
erator belt.
WARNING:Personal injury is possible while removing/installing the flywheel. The
flywheel weighs approximately 26 lbs (12 kgs) and can pinch or fall onto fingers or
other extremities causing personal injury.
Specifications
System Component Specification
Drive Belt Tension 70 - 76 lbs (31.8 - 34.5 kgs)
Generator Belt Tension 1/4 in (6.5 mm) belt deflection
1
Spinner® Chrono™ Power bike.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 85
5 Replacement Procedures
Drive Belt, Generator Belt, and Flywheel Replacement
