42 Assembling and Maintaining TRM 800-Series Treadmills
Cable Connector Type Circuit Connector
Location
Heart rate
sensors
Four-contact strip, keyed
Safety key
(treadmills
only)
Six-contact strip, keyed
CSAFE Eight-contact modular, on flat
gray cable
To simplify installation and maintenance, route and connect
cables 1 through 5 according to the following instructions.
Note: In the illustrations in this section, some cables are
omitted for the sake of clarity.
Connecting the Television Cable
The console’s television tuner is mounted inside the console’s
back plate. The tuner includes a short cable adapter that
allows the television cable to be connected outside the back
plate.
To connect the television cable:
1. Pull the cable out through the lower right corner of the
back plate.
2. Route the cable counterclockwise around the outside of
the back plate.
Important: In the following step, one of the two wrenches
should be a torque wrench set to 30 in-lb.
3. Attach the connector on the cable to the connector on the
tuner cable and tighten the two connectors securely using
two ⁷₁₆-inch open-end wrenches. Position both
connectors above the upper right corner of the back plate.
To Next Page
