Section 5 - MAINTENANCE

EAW530E2MV

Edition

03/2006

Only use fuses of the indicated amperage, identical to the original and of the semi-

rapid/delayed type, referring to the following table.

Section Amps Dimension Q.ty Code

FU1 - General 8.00 A 10 x 38 mm 3 KKE1253

FU2 – Tank 8.00 A 5 x 20 mm 1 KKE1238

FU3 – Tank - Manifold 8.00 A 5 x 20 mm 1 KKE1238

FU4 - Transformer 3.15 A 5 x 20 mm 1 KKE1268

FU5 – Hose 1 3.15 A 5 x 20 mm 1 KKE1268

FU6 – Gun 1 3.15 A 5 x 20 mm 1 KKE1268

FU7 – Hose 2 3.15 A 5 x 20 mm 1 KKE1268

FU8 – Gun 2 3.15 A 5 x 20 mm 1 KKE1268

5.7 SAFETY THERMOSTAT REPLACEMENT

Refer to figure 28 for the replacement of the safety thermostat.

Figure 28

Keep meticulously to the following table for the correct identification of the

thermostat, on the basis of the system used.

Code Description Q.ty

KKE1720 Low temperature version safety thermostat 1

KKE1760 Standard version safety thermostat 1

KKE1765 High temperature version safety thermostat 1
