38
Section 7 – TECHNICAL OUTLINES AND SPARE PARTS
© Copyright 2006 PREO SRL
All rights reserved
EAW530E2MV
Edition
03/2006
DE1000-MV EASY SERIES MANIFOLD GROUP + VALVE + PRESSURE GAUGE
POS
C
ODE
D
ESCRIPTION
UM
Q.
TY
NOTES
1
BC1000 Complete by-pass group for bulkmeter
NR
1
2
DER0020 Pressure transmitter reduction mn series
NR
1
3
KKH2005 Copper washer 27.00 x 21.00 x 02.00
NR
1
4
KKB1024 O-ring seal
NR
1
5
KKA2021 Straight fitting 3/8 g – ½” unf parker series
NR
1
6
KKC1009 Manifold screen isolation spacer easy series
NR
2
7
KKF1005 Socket head screw m5 x 10 stainless steel
NR
2
8
CE0170 Manifold stainless steel screen easy series
NR
1
9
KKA2014 Cap g 3/8 parker series
NR
3
10
KKB1046 O-ring seal
NR
3
11
KKH2017 Copper washer 22.00 x 17.00 x 01.50
NR
3
12
KKF1175 Socket head screw m8 x 100
NR
4
13
KKK1035 Zinc-plated schnorr type vs washer 8
NR
4
14
KKE1520 Heating element diam. 09.50 x 165.00 mm 300w 240v
NR
1
15
SEE TABLE 1 Filter group
NR
1
16
DER0010 Manifold body for easy series
NR
1
17
GGR3373 Cylindrical pin 6 x 16
NR
2
18
KKB1088 O-ring seal diam. 24.99 x 3.53
NR
1
19
FF3000 Quick release valve easy
NR
1
20
TGR1194 Pressure transmitter mn series
NR
1
TABLE 1 MANIFOLD FILTER REFERENCE TABLE
C
ODE
D
ESCRIPTION
Q.
TY
NOTES
DDR1130W Complete 1.00 filter group for easy applicator 1
DDR1131W Complete 2.00 filter group for easy applicator 1
