Section 7 – TECHNICAL OUTLINES AND SPARE PARTS
© Copyright 2006 PREO SRL
All rights reserved
EAW530E2MV
Edition
03/2006
VE0010 EASY SERIES TANK GROUP 5 KG GEARS
POS
C
ODE
D
ESCRIPTION
UM
Q.
TY
NOTES
1
VER0010 Tank easy series 5 kg
NR
1
2
VER0050 Spherical valve easy m/m ½ gas
NR
1
3
KKC1007 Insulating spacer lower tank foot easy
NR
4
4
KKC1022 Insulating spacer upper tank foot easy
NR
4
5
KKH1023 Zinc-plated flat washer 8.00 x 16.00 x 01.50 m8
NR
4
6
KKF1242 Socket head screw m8 x 50
NR
4
7
KKE1525 Heating element diam. 12.50 x 170.00 mm 450w 240v
NR
4
8
KKF1154 Socket head screw m4 x 8 stainless steel
NR
1
9
KKF1067 Socket head screw m3 x 6
NR
2
10
KKK1009 Zinc-plated schnorr type s washer 3
NR
2
11
See table 2 Safety thermostat
NR
1
12
KKE1601 4 x 25 probe cable mm 1200 for tank - manifold
NR
1
13
VER0035 Moulded seal kit easy series
NR
1
14
CE0110 Tank cover frame easy series
NR
1
15
VER0040 Cover support seal easy series
NR
1
16
CE0100 Tank cover hinge bracket easy series
NR
1
17
CE0120 Easy tank cover
NR
1
18
KKF1016 Socket head screw m6 x 16 unbrako
NR
2
19
KKC2001 Tank cover handle easy series
NR
1
20
KKK1026 Schnorr type vs washer 6
NR
2
21
KKG1004 Nut m6
NR
2
22
CE0130 Moulded counter-cover easy
NR
1
23
KKG1015 Nut m5
NR
2
24
KKF6102 Compression spring diam. 1.1 x 12 x 9.6
NR
2
25
CE0140 Counter-cover easy
NR
1
26
KKG1023 Hexagonal nut with spherical crown m5 stainless steel
NR
2
27
KKF1092 Socket head screw m5 x 20 unbrako
NR
12
28
KKK1020 Zinc-plated schnorr type vs washer 5
NR
12
29
CE0160 Tank protection network easy series
NR
1
TABLE 2 SAFETY THERMOSTAT REFERENCE TABLE
C
ODE
D
ESCRIPTION
Q.
TY
NOTES
KKE1720 Low temperature version safety thermostat 1
KKE1760 Standard version safety thermostat 1
KKE1765 High temperature version safety thermostat 1
