5
13. BLACK/YELLOW – Pulse During Crank Output (-)
At its default seng, the BLACK/YELLOW wire supplies a Ground (-) pulse when the engine cranks during remote start.
Note: This wire can be programmed to perform a dierent funcon by changing its opons. Refer to Bank 3, Feature 20
on page 10.
14. GREEN/ORANGE – Tach Input
The GREEN/ORANGE wire connects to the vehicle’s tach wire at the negave side of the ignion coil or fuel injector to
control engine crank during remote start.
Vericaon:
• Using a voltmeter set to AC volts, connect the voltmeter’s posive lead to a constant vehicle
12-Volts (+) source and the negave lead to the wire to be tested.
• Start the engine and have a partner slowly press the gas pedal while the transmission is in Park. If the voltage
increases as the RPM increases, this is the proper tach wire.
12. GREEN/YELLOW – Diesel Glow Plug Input (+)
The GREEN/YELLOW wire connect to the vehicle's Diesel Glow Plug detecon wire.
Vericaon: This wire will register as 12-Volt (+) while the Diesel Wait to Start Light is illuminated.
Detailed Descripons: Wire Harness Colors and Funcons
Input / Output Connector (14-pin connector) (Cont.) See page 22 for the full system diagram.
These wires are listed in order of their placement in the harness connector.
11. BLACK/RED – Pulse Aer Shutdown Output (-)
At its default seng, the BLACK/RED wire supplies a Ground (-) pulse when the remote start system is shut down. It
is typically used to re-lock vehicle doors aer remote start shutdown, or pulse the vehicle's door trigger to turn o
accessories aer vehicle shutdown.
Note: This wire can be programmed to perform a dierent funcon by changing its opons. Refer to Bank 3, Feature 22
on page 10.
10. DARK BLUE – Trunk Release Output (-)
At its default seng, the DARK BLUE wire connects to the vehicle trunk release wire or relay and supplies Ground (-)
when acvated from the remote control.
Vericaon: The vehicle trunk release wire registers 12-Volt (+) or Ground (-) when the trunk release buon is acvated.
