Diagnostics:
Diagnostic mode is automatic and will be displayed by ashing the parking lights a
number of times representative of the failed start, or premature shut down based on the
chart below. When a failure occurs, or a shut down occurs which in out of the ordinary
the parking lights will ash 1 thru 8 times immediately after to advise what the failure
could have been.
1 Flash Run timer expired
2 Flashes Low or no tach signal (RPM)
3 Flashes Positive inhibit wire activation
4 Flashes Manual Transmission Mode Error
5 Flashes RF shutdown signal received, or manual start trigger wire reactivated.
6 Flashes High tach signal (RPM)
7 Flashes Tach signal has not been learned
8 Flashes Negative inhibit wire activation
4 PIN DATA BUS PORT (DBI Port)
The 4 pin port located on the side of this module is for proprietary Flash-Logic data bus
interface modules. These modules are used to access a variety of features in the vehicle
which can be as simple as door trigger inputs, to more complex door lock outputs, or
transponder interfaces for remote starting. DO NOT connect anything to this port other
than the appropriate Data Bus Interface modules or damage to the Remote Start Could
occur. All installation instructions for the Data Bus modules will be packaged with the
individual component along with the proper 4 pin wiring harness requires to access the
data transmit & receive as well as the proper voltage levels for the interface.
