6 Pin Power Harness:
#
1124317
1 Blue Ignition 1 (+)
2 Red/White Battery 1 - 12V (+)
3 Green Ignition 2 (+)
4 Purple Accessory (+)
5 Red Battery 2 - 12V (+)
6 Yellow Starter Output
10 Pin Input/Output Harness:
#
1124316
1 Green/Orange Tachometer Input
2 Empty Cavity NA
3 Black/Blue Pulse Before Start
4 Black/LT. Green Pulse After Start
5 LT. Blue Ground While Running Output
6 Green/Yellow Glow Plug Input
7 Brown (+) Stop Input (Brake Sw.)
8 Gray (-) Negative Stop Input (Hood Sw.)
9 Black/Red Pulse After Shutdown
10 Black/Yellow Pulse During Crank
4 Pin Main Harness:
#
1124320
1 Black Ground
2 White/Red Parking Light Relay Input
3 Yellow/Black To Controlling Alarm’s Ign. Inputt
4 White Parking Light Relay Output
