Pride Q6 Edge - Page 13

NE + OR Q-LOGIC (BEYOND 2012)
NE+ JOYSTICK SHOWN
Handcontrol Settings
Alternative Controls
Attendant Joystick
Specialty Control
Enhanced Display
Seat
System Settings
7/7
Program Adjustments
General Drive
Motor & Wheels
Settings - Miscellaneous
Battery
Reset Distance
3/5
Program Adjustments/
System Settings
Save System Configuration
Latch Timout Disable No
Inhibit high active
3/3
Program Adjustments/System Settings/
Settings - Miscellaneous
VERIFY THE INHIBIT PROGRAM.
The “Inhibit” program should be set to “High.”
What type of electronics
are used on this chair?
NE
i1 i2 i3
Active Off OffOn
On OnOnactiveH
OOO
proSel
Off OffOndrvInh
Off OffOnchrgInb
General Drive
Timing
Motors & Wheels
Battery
Inputs
Miscellaneous
PROGRAM
NE JOYSTICK
SHOWN
VERIFY THE INHIBIT PROGRAM.
“chrgInb” should be set to “ON.”
Was the inhibit pro-
grammed correctly?
Reprogram the inhibit
and retest the system.
NO YES
Replace the power mod-
ule and retest the system.
13
VERIFY THE INHIBIT PROGRAM.
The “Inhibit” program should be set to “High.”
NE+ JOYSTICK SHOWN
NE + OR Q-LOGIC (PRIOR TO 2012)
