Pride Q6 Edge - Page 21

21
Disconnect the charger
power cord from the off-
board power charger.
ELECTRICAL OUTLET
INDICATES ABOUT
120VAC FOR BOTH
TESTS
Replace the off-
board charger
and retest the
system.
DOES NOT INDICATE ABOUT
120VAC FOR BOTH TESTS
Unplug the charger power cord
from the electrical outlet.
CHARGER POWER CORD
INDICATES ABOUT
120VAC FOR BOTH
TESTS
DOES NOT INDI-
CATE ABOUT
120VAC FOR BOTH
TESTS
Replace the
charger power
card and retest
the system.
Try a different
electrical outlet
and retest the
system.
