Container width: 1.0" to 9.4" (25.4mm to 238.8mm)
Container diameter: 0.6" to 6.7" (15.2mm to 170.2mm)
Container shape: Cylindrical and many tapered
Supply roll diameter: Up to 8" (203mm)
Media liner width: 1.00" to 8.38" (25.4mm to 213.0mm)
Supply roll core: 2" to 3" ID (51.8mm to 76.2mm)
Electrical rating: 12 VDC, 5.0A
Power requirements: 100-240 VAC, 50/60 Hz, 60 watts
Feed speed: 4.0 in/sec. in Default Mode.
2.0 in/sec in Half-Speed mode for 6-8" wide label
See Section 4A, Step 2 for details.
Agency certifications: UL, UL-C, CE, FCC Class B
Weight: 16 lb (7.3 kg)
Dimensions: 13.4"W x 8.9"H x 12.9"D
(340mm W x 226mm H x 328mm D)
Label width: 0.75" to 8.25" (19.1mm to 209.6mm)
Label height/length: 0.75" to 24.00" (19.1mm to 609.6mm)
18 AP360/362 Label Applicator
Section 7: Specifications
